input:
4 to 32 vdc

model
->

svda/
3v10

svda/
3v25

svda/-
3v50

svda/-
3v75

svda/-
6v50

svda/-
6v75

impedance (rc)

ohm

1500

1500

1500

1500

1500

1500

turn-on voltage (min.)

vdc

4v@5.4ma

4v@5.4ma

4v@3.5ma

4v@3.5ma

4v@3.5ma

4v@3.5ma

turn-on voltage (max.)

vdc

32v@10ma max (current limited)

32v@10ma max (current limited)

32v@6.5ma max (current limited)

32v@6.5ma max (current limited)

32v@6.5ma max (current limited)

32v@6.5ma max (current limited)

turn-off voltage (max.)

vdc

1

1

1

1

1

1

reverse voltage protection

vdc

-75

-75

-75

-75

-75

-75

input: 100 to 280 vac

model
->

svaa/
3v10

svaa/
3v25

svaa/
3v50

svaa/
3v75

svaa/
6v50

svaa/
6v75

schematic number

0

2

2

2

2

2

2

impedance (rc)

kohm

20

20

20

20

20

20

turn-on voltage (min.)

vac

100

100

100

100

100

100

turn-off voltage (max.)

vac

20

20

20

20

20

20

reverse voltage protection

n/a

n/a

n/a

n/a

n/a

n/a

output: (for all models)

i out (continuous w/proper heatsink)

a rms

10

25

50

75

50

75

voltage【敏感詞】@ i out

vac

1.1

1.2

1.3

1.1

1.3

1.1

i surge - 1 cycle non-repetitive

a peak

100

250

650

950

650

950

i surge - 1 second non-repetitive

a peak

40

100

130

140

130

140

voltage range (v out )

vac

24-330

24-330

24-330

24-330

24-660

24-660

peak blocking voltage

800

800

800

800

1200

1200

frequency range

hz

47-63

47-63

47-63

47-63

47-63

47-63

leakage @ v out (max.)

ma

8

8

8

8

8

8

turn-on (max.)

1/2 cycle

1/2 cycle

1/2 cycle

1/2 cycle

1/2 cycle

1/2 cycle

turn-off (max.)

1/2 cycle

1/2 cycle

1/2 cycle

1/2 cycle

1/2 cycle

1/2 cycle

holding current (min.)

ma

50

50

50

50

50

50

zero voltage switching

yes

yes

yes

yes

yes

yes

dv/dt @ v out (max.)

vus

750

750

1000

1000

500

500

commutating dv/dt
snubbed for power factor.=

.5

.5

.5

.5

.5

.5

i 2 t fusing (8.3 ms.)

a 2 s

35

260

1035

3745

1035

3745

thermal resistance r 0jc (tj=115 o c)

0 c/w

1.48

1.05

.65

.30

.65

.65

general characteristics:

dielectric strength (input-output-base)

v rms

4000

4000

4000

4000

4000

4000

capacitance input to output

pf

3

3

3

3

3

3

ambient temp. range (operating)

0 c

-40 to +100

-40 to +100

-40 to +100

-40 to +100

-40 to +100

-40 to +100

adequate heatsinking, including consideration of air temperature【敏感詞】flow, is essential to the proper operation of a solid state relay. units should not be mounted in an enclosed area without proper air flow. units should also never be mounted to a plastic base【敏感詞】to a painted surface. proper thermal transfer gel【敏感詞】pad should be applied to the heatsink before mounting the relay. failure to provide adequate heatsinking will cause a solid state relay to fail.
