杜  邦pet rynite同系列型號介紹

rynite fr515 bk507 15％ glass reinforced,v-0 at 0.8 mm (0.031 inch)

rynite fr515 nc010 15％ glass reinforced,v-0 at 0.8 mm (0.031 inch)

rynite fr530 bk507 30％ glass reinforced,flame retardant, black, modified pet recognized by ul as ul94v-0 at 0.35mm.

rynite fr530 nc010 30％ glass reinforced,flame retardant, modified pet approved by ul as ul94v-0 @ 0.35mm.

rynite fr530l nc010 30％ glassreinforced, flame retardant, lubricated, modified pet recognized by ul asul94v-0 at 0.35mm.

rynite 935 bk505 35％ mica/glassreinforced modified pet with exceptionally low warpage, excellent electricalproperties, high stiffness,【敏感詞】high heat resistance.

rynite 935 nc010 35％ mica/glassreinforced modified pet with exceptionally low warpage, excellent electricalproperties, high stiffness,【敏感詞】high heat resistance.

rynite 935suv bk593 35％ glassfiber/mineral reinforced, uv stabilized, modified polyethylene terephthalateresin with low warpage

rynite 940 bk505 40％ glass/mineralreinforced

rynite fr945 bk507 45％ glass/mineralreinforced, v-0 at 0.031 inch

rynite fr945 nc010 45％ glass/mineralreinforced, v-0 at 0.031 inch

rynite re5231 bk533 35％ glass/micareinforced

rynite 530hte bk503 30％ glass reinforcedproduct with excellent high temperature dielectric properties

rynite 530hte nc010 30％ glass reinforcedproduct with excellent high temperature dielectric properties

rynite 408 bk515 toughened, 30％ glassreinforced

rynite 408 nc010 toughened, 30％ glassreinforced

rynite 415hp bk503 15％ glass reinforcedmodified pet improved for easy, fast processing over a broad molding range withexcellent balance of strength, stiffness,【敏感詞】temperature resistance

rynite 415hp nc010 15％ glass reinforcedmodified pet improved for easy, fast processing over a broad molding range withexcellent balance of strength, stiffness,【敏感詞】temperature resistance

rynite sst35 bk503 toughened, 35％ glassreinforced

rynite sst35 nc010 toughened, 35％ glassreinforced

rynite 515cs bk575m 15％ glassreinforced, color stable

rynite 530 bk503 30％ glass reinforced

rynite 530 nc010 30％ glass reinforced

rynite 540suv bk544 40％ glass fiberreinforced, uv stabilized, modified polyethylene terephthalate resin forinjection molding【敏感詞】extrusion, developed for outdoor applications requiringhigh stiffness.

rynite 545 bk504 45％ glass reinforced

rynite 545 nc010 45％ glass reinforced

rynite 830er bk503 30％ glass reinforced

rynite 830er nc010 30％ glass reinforced

rynite® 530 bk503

thermoplastic polyester resin

30％ 玻璃纖維增強材料

dupont performance polymers

產品說明:

rynite® 530 bk503是一種thermoplastic polyester resin產品,含有的填充物為30％ 玻璃纖維增強材料。 它可以通過注射成型進行加工,在北美洲、非洲和中東、拉丁美洲、歐洲或亞太地區有供貨。 rynite® 530 bk503的應用領域包括汽車行業 和 電線電纜。

總體

材料狀態  已商用：當前有效

資料 1  processing - injection molding (english)

typical processing for dupont engineering polymers (english)

ul 黃卡 2  e41938-257700

搜索 ul 黃卡  dupont performance polymers

rynite®

供貨地區  北美洲

非洲和中東

拉丁美洲

歐洲

亞太地區

填料/增強材料  玻璃纖維增強材料, 30％ 填料按重量

機構評級  ul 未評級

加工方法  注射成型

部件標識代碼 (iso 11469) >pet-gf30<

樹脂id (iso 1043) pet-gf30

物理性能 額定值 單位制 測試方法

密度 1.56 g/cm3 iso 1183

收縮率     iso 294-4

橫向流量 0.90 ％

流量 0.30 ％

機械性能 額定值 單位制 測試方法

拉伸模量 10200 mpa iso 527-2

拉伸應力 (斷裂) 150 mpa iso 527-2

拉伸應變 (斷裂) 2.1 ％ iso 527-2

彎曲模量 8940 mpa iso 178

彎曲強度 210 mpa iso 178

沖擊性能 額定值 單位制 測試方法

簡支梁缺口沖擊強度     iso 179/1ea

-40°c 8.0 kj/m2

-30°c 8.5 kj/m2

23°c 9.5 kj/m2

簡支梁缺口沖擊強度     iso 179/1eu

-40°c 45 kj/m2

23°c 52 kj/m2

懸壁梁缺口沖擊強度     iso 180/1a

-40°c 8.5 kj/m2

23°c 9.5 kj/m2

無缺口伊佐德沖擊強度     iso 180/1u

-40°c 35 kj/m2

23°c 45 kj/m2

熱性能 額定值 單位制 測試方法

熱變形溫度

0.45 mpa, 未退火 244 °c iso 75-2/b

1.8 mpa, 未退火 221 °c iso 75-2/a

電氣性能 額定值 單位制 測試方法

耐電強度 32 kv/mm iec 60243-1

可燃性 額定值 單位制 測試方法

燃燒速率 (1.00 mm) 38 mm/min iso 3795

可燃性等級     iec 60695-11-10, -20

0.810 mm hb

1.50 mm hb
